Operating Pressure 350BAR
Pressure Range 3bar-330bar ,Preset:150bar
Internal Leakage 82ml/min.max.to 80% of norminal setting
Temperature -30°C to +120°C(-22°F to+250°F)
Cavity RV-G1/2 see page K-27
Fluids Mineral-based fluids with viscosities of 7.4 to 420 cSt.
Fast response to pressure surges
Hardened poppet and seat for long life
Adjustment may be locked in place
Industry common cavity
Adjustment prevents spring from going solid
Pilot-operated, balanced-piston relief cartridges are normally closed
pressure regulating Valve. When the pressure at the inlet (port 1) reaches
the valve setting, the valve starts to open to tank (port 2), throttling flow to
regulate the pressure. These Valves are accurate, have low pressure rise
vs. flow, they are smooth and quiet, and are moderately fast.
