Operating Pressure 350BAR
Response Time - Typical 10ms
Internal Leakage 30ml/min.max.at 70bar
Temperature -30°C to +120°C(-22°F to+250°F)
Cavity T-162A see page K-7
Fluids Mineral-based fluids with viscosities of 7.4 to 420 cSt.
Main stage orifice is protected by a stainless steel screen.
Back pressure on the tank port (port 2) is directly additive to the
valve setting at a 1:1 ratio.
Will accept maximum pressure at port 2; suitable for use in cross
port relief circuits. If used in cross port relief circuits, consider
Pilot-operated, balanced-piston relief cartridges are normally closed
pressure regulating Valve. When the pressure at the inlet (port 1) reaches
the valve setting, the valve starts to open to tank (port 2), throttling flow to
regulate the pressure. These Valves are accurate, have low pressure rise
vs. flow, they are smooth and quiet, and are moderately fast.
