Operating Pressure 460BAR
Pressure Range 0bar-33bar ,Prese1.7bar
Internal Leakage 5drops/min.max.to 80% of norminal setting
Temperature -30°C to +120°C(-22°F to+250°F)
Cavity 08-2 see page K-9
Fluids Mineral-based fluids with viscosities of 7.4 to 420 cSt.
Hardened,precision ground parts for durability
Industry common cavity
Adjustment may be locked in place
Low leakage design
Fast response to pressure surges
The valve prevents flow from ① to ② until the set crack pressure at ① is
achieved.The poppet then unseat allowing flow from ① to ②
protecting the circuit from over pressurization.
