MCXFA-Wenzhou Meric Hydraulic Technology Co.,Ltd

Category：

Cartridge valve

Directional valve

方向阀

MCXFA

Features Hardened,precision ground parts for durability Industry common cavity Compact size Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min). Will accept 5000 psi (350 bar) at ports 1 and 2

You can send us an email：

sales1@meric.cn

sales2@meric.cn

MESSAGE

Product Details

MCXFA MCXFA

Specifications

Operating Pressure 350BAR

Flow 160L/min

Internal Leakage 0.07ml/min.max.at operating pressure

Temperature -30°C to +120°C(-22°F to+250°F)

Cavity T-5Asee page K-36

Fluids Mineral-based fluids with viscosities of 7.4 to 420 cSt.

Features

Hardened,precision ground parts for durability

Industry common cavity

Compact size

Check valves offer extremely low leakage rates with a maximum

leakage of less than 1 drop per minute (0,07 cc/min).

Will accept 5000 psi (350 bar) at ports 1 and 2

Operation

Free-flow, nose-to-side check Valve are on/off circuit components that

allow free flow from the inlet (port 1) to the outlet (port 2) and block flow in

the opposite direction.
