Operating Pressure 250BAR
Flow Setting 0.4- 13.2L/min
Flow Maintenance Accuracy 0.2 to 1.8lpm.settings±15%
1.9 to 7.5lpm.settings±10%
Temperature -30°C to +120°C(-22°F to+250°F)
Cavity 08-2 see page K-9
Fluids Mineral-based fluids with viscosities of 7.4 to 420 cSt.
Hardened,precision ground parts for durability
Industry common cavity
The valve maintains a constant flow rate out of ② regardless of load
pressure changes in the circuit downstream of ②．The fixed control
orifice is factory preset to customer flow specification.The valve begins to
respond to load changes when the flow through the valve creates a
pressure differential across the control orifice greater than 5.5 bar, with
accurate flow maintenance from 7.6 to 240 bar. Reverse flow( ② to ① )
returns through the control orifice and is non-compensated.
