MADRV2-10-Wenzhou Meric Hydraulic Technology Co.,Ltd

Category：

Cartridge valve

Pressure control valve

Relief valve

MADRV2-10

Features Hardened,precision ground parts for durability Industry common cavity Compact size Adjustment may be locked in place Low leakage design Fast response to pressure surges

You can send us an email：

sales1@meric.cn

sales2@meric.cn

MESSAGE

Product Details

MADRV2-10

Specifications

Operating Pressure 230BAR

Flow 37.9L/min

Internal Leakage 5drop/min.max.to 80% of norminal setting

Temperature -30°C to +120°(-22°F to+250°F)

Cavity 10-2 see page K-11

Fluids Mineral-based fluids with viscosities of 7.4 to 420 cSt.

Features

Hardened,precision ground parts for durability

Industry common cavity

Compact size

Adjustment may be locked in place

Low leakage design

Fast response to pressure surges

Operation

The valve prevents flow from ① to ② until the set crack pressure at ① is

achieved.The poppet then unseat allowing flow from ① to ②

protecting the circuit from over pressurization.

None
