Special function valve
Features Handened ,precison ground paet for durability Indestry common cavity Compact size Low pressure drop
You can send us an email：
Operating Pressure 345BAR
Internal Leakage 164ml/min.max.at operating pressure
Temperature -30°C to +120°C(-22°F to+250°F)
Cavity 20-S3 see page K-34
Fluids Mineral-based fluids with viscosities of 7.4 to 420 cSt.
Handened ,precison ground paet for durability
Indestry common cavity
Low pressure drop
The valve is a spring-biased blocking valve which will shift to allow full flow
from ① to ② only when pressure at ① exceeds the cumulative pressure of ③,
plus the bias spring pressure value.
When no pressure at ③,flow will be allowed from ① to ② once the bias spring
force is overcome with pressure at ① .
