MHF08-242-Wenzhou Meric Hydraulic Technology Co.,Ltd

Category：

Solenoid control valve

二位四通

Cartridge valve

MHF08-242

Features Hardened,precision ground parts for durability Industry common cavity Efficient wet-armature construction Continuous-duty solenoid

You can send us an email：

Product Details

MHF08-242

Specifications

Operating Pressure 210BAR

Flow 11.4L/min

Internal Leakage 82ml/min.max.at operating pressure

Temperature -30°C to +120°C(-22°F to+250°F)

Cavity 08-4 see page K-10

Fluids Mineral-based fluids with viscosities of 7.4 to 420 cSt.

Features

Hardened,precision ground parts for durability

Industry common cavity

Efficient wet-armature construction

Continuous-duty solenoid

Operation

When de-energized, the valve flow paths are port ② to port ①, and

port ③ to port ④;

When energized, the valve's spool shifts to open port 3 to port ②, and

port ④ to port ①.
