Operating Pressure 207BAR
Internal Leakage 3drop/min.max.at operating pressure
Temperature -30°C to +120°C(-22°F to+250°F)
Cavity 10-2 see page K-11
Fluids Mineral-based fluids with viscosities of 7.4 to 420 cSt.
Hardened,precision ground parts for durability
Industry common cavity
Efficient wet-armature construction
When de-energized, the poppet lifts to open flow from ② to ① . Flow is also
open from ① to ② .
When energized ,the cartridge acts as a check valve, allowing flow from ①
to ②while blocking flow from ② to ① , after overcoming the solenoid force
(requires 3.4 to 10.3bar [50 to 150 psi).
