MSC5H
Features Hardened,precision ground parts for durability Industry common cavity Compact size Low leakage design
You can send us an email:
Product Details
Specifications
Operating Pressure 207BAR
Flow 50L/min
Internal Leakage 5drop/min.max.at operating pressure
Temperature -30°C to +120°C(-22°F to+250°F)
Cavity SC5H see page K-31
Fluids Mineral-based fluids with viscosities of 7.4 to 420 cSt.
Features
Hardened,precision ground parts for durability
Industry common cavity
Compact size
Low leakage design
Operation
Pressure at ② overcomes the spring-bias poppet and allows free flow
② to ①.When the pressure of ③ exceeds the pressure of ①,
① Interchange to ②
