Operating Pressure 207BAR
Internal Leakage 82ml/min.max.at operating pressure
Temperature -30°C to +120°C(-22°F to+250°F)
Cavity 08-4 see page K-10
Fluids Mineral-based fluids with viscosities of 7.4 to 420 cSt.
Hardened,precision ground parts for durability
Industry common cavity
Efficient wet-armature construction
The valve will block from ① to ②,④ to ③.
Flow is allowed in the direction,when pressure is applied to port ① and or
The valve has a 2.5:1 pliot ratio,so at least 1/2.5 of the load pressure at ①
is required at port ③ or ④ (when energized,allows flow ④ to ③),to open
the flow passage to allow from ① to ②.
