Operating Pressure 207BAR
Internal Leakage 82ml/min.max.at operating pressure
Temperature -30°C to +120°C(-22°F to+250°F)
Cavity 08-3 see page K-9
Fluids Mineral-based fluids with viscosities of 7.4 to 420 cSt.
Hardened,precision ground parts for durability
Industry common cavity
Efficient wet-armature construction
When energized, the valve allows flow from port ② to port ① or from
port ① to port ② free mobility , while blocking flow at port ③;
When de-energized, the valve's spool shifts open from port ③ to port
① or from port ① to port ③ , while blocking flow at port ② .
