Operating Pressure 207BAR
Internal Leakage 3drop/min.max.at operating pressure
Temperature -30°C to +120°C(-22°F to+250°F)
Cavity 10-2 see page K-11
Fluids Mineral-based fluids with viscosities of 7.4 to 420 cSt.
Hardened,precision ground parts for durability
Industry common cavity
Efficient wet-armature construction
When de-energized, the valve allows flow from ② to ① . Flow from ① to ②
is severely restricted in this mode.
When energized the valve’s poppet closes on its seat, blocking flow from
② to ① .The cartridge will allow ① to ② flow after overcoming the solenoid
